规格参数表
型号 | 电压 (V) | 容 量 /Ah (C20@25℃ ) | W/cell 1.67V@15min | 内阻 (m Ω) | 外形尺寸 (mm) | 重量(Kg) | 端子类型 | |||
L | W | H | TH | |||||||
C12-18-AH | 12 | 18 | 61.7 | 16.2 | 181.5 | 77 | 155.5 | 167.5 | 5.4 | M5 |
C12-26-AH | 12 | 26 | 89.1 | 12 | 166 | 175 | 115 | 125 | 7.8 | M5 |
C12-38-AH | 12 | 38 | 123 | 9 | 197 | 165 | 156 | 170 | 11.4 | M6 |
C12-65-AH | 12 | 65 | 210 | 6.5 | 325 | 167 | 170 | 174 | 19.2 | M6 |
C12-100-AH | 12 | 100 | 324 | 4 | 330 | 173 | 216 | 220 | 28 | M8 |
C12-120-AH | 12 | 120 | 336 | 3.8 | 408 | 177 | 211 | 225 | 32.3 | M8 |
C12-150-AH | 12 | 150 | 420 | 3.5 | 483 | 170 | 225 | 238 | 41.5 | M8 |
C12-200-AH | 12 | 200 | 560 | 3.2 | 522 | 240 | 218 | 224 | 57.1 | M8 |
C12-250-AH | 12 | 250 | 700.4 | 2.6 | 522 | 240 | 218 | 224 | 63.5 | M8 |
